LL2760 Lundahl - Power supply transformer

Trasformatore Lundahl di alimentazione LL2760 C-core. 200VA. Peso e dimensioni nel datasheet

Primari: 230V/115V

Secondari: 115-0-115V / 0.9A x 2

C-core mains transformer for 2 x 115V / 0.9A . The core is assembled with a small air-gap to compensate for any mains DCunbalance. Estimated power rating 200 VA (heat dissipation 11W) which can be increased with good cooling. Magnetic stray is extremely small due to the dual coil structure. A Faraday shield is provided between primary and secondary windings to improve immunity from mains HF noise.
