SP18R Passive (H9944) Seas

94,26 €
Tempi di consegna dai 4 ai 7 giorni
Seas

SEAS Prestige SP18R (H9944) radiatore passivo, sospensione in  gomma, Fs 25Hz, VAS 46lt, MMS 20gr, RMS 0,317 Kg/s

Quantità

SP18R is a passive radiator intended for use as an alternative to the port in a bass
refl ex cabinet, together with an active woofer of similar size or smaller.
In many applications the traditional bass refl ex port may produce high speed air
noise or even have poor effect due to a small port area or a large port length. In
such cases, a passive radiator may bring about an improvement.
The chart below will show you the mass which has to be added to the cone of the
passive radiator in order to obtain the desired Helmholtz resonance frequency in a
given cabinet volume.
The passive radiator cone is equipped with an M4mm screw to which you can easily
attach the added mass.
For optimum performance, the passive radiator should be mounted vertically (with
horizontal cone axis) This is especially important when a signifi cant additional mass
is used.
