Scan Speak 32W/4878T01 Paper revelator

Scan Speak 32W/8878T11 Paper revelator

€630.33
In Stock
Scan Speak

Scan Speak Revelator 28W-4878T00 Woofer hard paper cone 4 ohm + gomma+logo Fs 18Hz, Sensitivity 88.2db, RMS 200w Qts 0.3

DOWNLOAD DATASHEET for graphic, measures, dimensions

Quantity

WOOFER 28W/4878T00
The 28W/4878T00 is a very powerful 28cm sub woofer, with its large 3” voice coil,
extreme linear excursion and low resonance frequency is it perfect to reproduce the
deepest frequencies. It features a paper-sandwich cone with very high stiffness and
relative low weight. The motor system has heavy duty copper sleeves for optimizing
eddy currents and minimizing self-induction.

KEY FEATURES:
· Paper sandwich cone
· Spider with balanced tinsel leads
· 3” Voice coil, Titanium former and paper reinforced
· Patented Symmetrical Drive motor
· Extreme linear excursion (+/-14 mm)

· Stiff and strong die cast aluminium chassis


T-S Parameters
Datasheet updated: May 15. 2017
Resonance frequency [fs] 18 Hz
Mechanical Q factor [Qms] 5.6
Electrical Q factor [Qes] 0.32
Total Q factor [Qts] 0.3
Force factor [Bl] 11.2 Tm
Mechanical resistance [Rms] 2.3 kg/s
Moving mass [Mms] 114.5 g
Compliance [Cms] 0.68 mm/N
Effective diaph. diameter [D] 215 mm
Effective piston area [Sd] 363 cm²
Equivalent volume [Vas] 127 l
Sensitivity (2.83V/1m) 88.2 dB
Ratio Bl/√Re 6.36 N/√W
Ratio fs/Qts 60 Hz
Electrical Data
Voice Coil & Magnet Data
Nominal impedance [Zn] 4 Ω
Minimum impedance [Zmin] 3.8 Ω
Maximum impedance [Zo] 53 Ω
DC resistance [Re] 3.1 Ω
Voice coil inductance [Le] 0.5 mH
Power Handling
100h RMS noise test (IEC 17.1) 200 W
Long-term max power (IEC 17.3) 500 W
Voice coil diameter 75 mm
Voice coil height 36 mm
Voice coil layers 2
Height of gap 8 mm
Linear excursion ± 14 mm
Max mech. excursion ± 26 mm
Unit weight 7.5 kg
