LL1649 Lundahl - Power supply transformer

Trasformatore Lundahl di alimentazione LL1649 C-core. 250VA. Peso e dimensioni nel datasheet

Primari: 230V/115V

Secondari: 230V / 1.0A - 6.6V / 3.1A

C-core mains transformers. The core is assembled with a small air-gap to compensate for any mains DCunbalance. Estimated power rating 250 VA which can be increased with good cooling. Magnetic stray is extremely small if secondaries of the two coils are loaded identically
