LL1669A Lundahl - Power supply transformer

Trasformatore Lundahl di alimentazione LL1669A C-core. 250VA. Peso e dimensioni nel datasheet

Primari: 230V/115V

Secondari: 340V / 0.35A - 6.3V / 3.1A

C-core mains transformer. The core is assembled with a small air-gap to compensate for any mains DC-unbalance. Estimated power rating 250 VA which can be increased with good cooling. Magnetic stray is extremely small if secondaries of the two coils are loaded identically
