LL1674 Lundahl - Line input/output transformer

LL1674 Lundahl - trasformatore per ingresso/uscita linea, nucleo amorfo. Info collegamenti nel datasheet

Turns ratio: 1 + 1 : 4 + 4

Dims (Length x Width x Height above PCB (mm)): 43 x 28 x 21

The LL1674 is a large, high signal level audio transformer built with the well know Lundahl amorphous core. The LL1674 consists of two coils, each with a two-sectioned primary winding and a high level secondary winding separated by electrostatic shields. The core is a two-component amorphous strip core. The very high mu of the core results in a phase shift of less than 0.5 degree at 10Hz. The transformer is magnetically shielded by a mu metal housing.
