LL1676 Lundahl - Line input/output transformer

LL1676 Lundahl - trasformatore per ingresso/uscita linea, nucleo amorfo. Info collegamenti nel datasheet

Turns ratio: 1 + 1 : 2 + 2

Dims (Length x Width x Height above PCB (mm)): 43 x 28 x 21

The LL1676 is a large, high level, high performance audio transformer built with the well know Lundahl amorphous core The LL1676 consists of two coils, each with a two-sectioned primary winding and a high level secondary winding separated by electrostatic shields. . The core is a two-component amorphous strip core. The very high mu of the core results in a phase shift of less than 0.5 degree at 10Hz. The transformer is magnetically shielded by a mu metal housing.
