LL1683 Lundahl - Power supply transformer

Trasformatore Lundahl di alimentazione LL1683 C-core. 250VA. Peso e dimensioni nel datasheet

Primari: 230V/115V

Secondari: 250-0-250V / 0.16A - 6.6V / 3A - 5.2V / 3A - 48V / 0.1A

C-core mains transformer. The core is assembled with a small air-gap to compensate for any mains DC-unbalance. Estimated power rating 120 VA, which can be increased with good cooling. The 2 x 250V secondaries are internally divided between the two coils. As a result, the transformer can be used with bridge or full wave rectifiers without a problem of asymmetric load. Magnetic stray is extremely small if filament secondaries of the two coils are loaded identically.
