LL1933 Lundahl MC input Transformer 1:8 o 1:16 - nucleo Mu metal e rame Cardas

LL1933 Trasformatore step up per testina MC (moving coil)

Rapporto: 1+1 : 8+8

Dimensioni: 47x28x24

- Permalloy lamination core.

- Cardas Audio copper

Prestigious moving coil transformer, 1:8 or 1:16. Cardas Audio copper and classic Permalloy lamination core.

LL1933 is a high performance moving coil step-up transformer. The transformer combines our dual coil structure with
Cardas high purity copper wire in an oversized design. The objective with LL1933 is to provide an alternative for the
successful amorphous core LL1931 for those who prefer a low distortion, linear magnetization curve nickel lamination
core transformer. The dual-coil structure greatly improves immunity to external magnetic fields from power supplies,
motors etc. The transformer is housed in a mu-metal can.
Turns ratio: 1 + 1 : 8 + 8

Dimensions (L x W x H above PCB, in mm) 47 x 28 x 24
Spacing between pins 5.08 mm (0.2")
Spacing between rows of pins 35.6 mm (1.4")
Rec. PCB hole diameter: 1.5 mm
Weight: 115 g
Static resistance of each primary: 1.5 Ω
Static resistance of each secondary: 85 Ω
Frequency response (serial connection, source 50 Ω,
no load / secondaries open):
8 Hz -- 100 kHz +/- 1.0 dB
Isolation between windings/ between windings and core: 3 kV / 1.5 kV

Disponibilità dai 7 ai 15 giorni
