LL1963 Lundahl MC input Transformer per pre phono a stato solido - nucleo Mu metale e rame Cardas

LL1963 Trasformatore step up per testina MC (moving coil)

Rapporto 1: 3,1
1: 6,2

Dimensioni 43x28x24

- Mu metal core.

- Cardas Audio copper

Prestigious moving coil transformer, 1:3,1 or 1:6,2. Cardas Audio copper and Lundahl Mu Metal core. Consigliato per pre a stato solido

LL1963 is a low turns ratio, low impedance moving coil step-up transformer. The LL1963 transformer combines our dual coil structure with Cardas high purity copper wire in an oversized design. The objective with LL1963 is to provide an alternative suitable for solid state systems, where the classical high turns ratio transformers are not required. The mu metal laminations results in low distortion and a linear magnetization curve. The purpose of the Faraday shield is to make galvanic isolation between cartridge and phono-stage possible. The dual-coil structure greatly improves immunity to external magnetic fields from power supplies, motors etc. The transformer is housed in a mu-metal can.

Disponibilità dai 7 ai 15 giorni
