LL2738 Lundahl - Power supply transformer

Trasformatore Lundahl di alimentazione LL2738 C-core. 250VA. Peso e dimensioni nel datasheet

Primari: 230V/115V

Secondari: 110V / 0.1A - 6.6V / 3A x 8

LL2738 is a C-core (with small air gap) mains transformer for applications where a large number of tube filaments needs supply. Estimated power rating 160 VA which can be increased with good cooling. Magnetic stray is small if the two coils are loaded symmetrically
