LL2758 Lundahl - Power supply transformer

Trasformatore Lundahl di alimentazione LL2758 C-core. 100VA. Peso e dimensioni nel datasheet

Primari: 230V/115V

Secondari: 250-0-250V / 0.13A x 2 - 6V / 2A - 6V / 2A - 30V / 0.1A

C-core mains transformer, assembled with a small core air-gap to compensate for any mains DC-unbalance. Estimated power rating 100 VA, which can be increased with good cooling. The 2 x 250V secondaries are internally divided between the two coils. As a result, the transformer can be used with bridge or full wave rectifiers without a problem of asymmetric load. Magnetic stray is extremely small if filament secondaries of the two coils and the 15V-0-15V winding are loaded symetrically
