GA10 SC64 - 10" Signature Guitar speaker - 8 ohm

133,50 €

Tasse incluse Tempi di consegna dai 3 ai 4 giorni

Ultimi articoli in magazzino

Marca

GA10 SC64" impedenza 8 ohm, 20w massimi. Cono da 10 pollici, serie Signature, cestello American standard, magnete in ferrite. Ideato dal noto costruttore di amplificatori George Alessandro

Dinamica bassi: moderata

Timbrica bassi: asciutta/punchy

Dinamica medi: moderata

Timbrica medi: calda

Risposta alti: moderata

Sensibilità (volume): medio alta

SPECIFICATION
Nominal Basket Diameter	10", 254 mm
Nominal Impedance*	8 Ω
Power Rating*
Program Power	N/A
Watts	20 W
Resonance	100 Hz
Usable Frequency Range	100 Hz - 5.5 kHz
Sensitivity*	98.2 dB
Magnet Weight	15 oz.
Gap Height	0.25", 6.4 mm
Voice Coil Diameter	1", 25 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)	100 Hz
DC Resistance (Re)	7.58 Ω
Coil Inductance (Le)	0.48m H
Mechanical Q (Qms)	16.89
Electromagnetic Q (Qes)	1.38
Total Q (Qts)	1.28
Compliance Equivalent Volume (Vas)	33.49 liters / 1.18 cu.ft.
Peak Diaphragm Displacement Volume (Vd)	58.2 cc
Mechanical Compliance of Suspension (Cms)	0.18 mm/N
BL Product (BL)	7.05 T-M
Diaphragm Mass Inc. Airload (MMs)	14 grams
Efficiency Bandwidth Product (EBP)	72
Maximum Linear Excursion (Xmax)	1.59 mm
Surface Area of Cone (Sd)	366.1 cm2
Maximum Mechanical Limit (Xlim)	N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed	Acceptable
Vented	Acceptable
Driver Volume Displaced	0.027 cu.ft. / 0.77 liters
Overall Diameter	10.11", 256.8 mm
Baffle Hole Diameter	9.13", 231.9 mm
Front Sealing Gasket	Yes
Rear Sealing Gasket	N/A
Mounting Holes Diameter	0.22", 5.6mm
Mounting Holes B.C.D.	9.6", 243.8mm
Depth	3.93", 99.7 mm
Net Weight	3.3 lbs, 1.5 kg
Shipping Weight	4.4 lbs, 2 kgs
MATERIALS OF CONSTRUCTION
Coil Construction	Copper voice coil
Coil Former	Paper former
Magnet Composition	Ferrite magnet
Core Details	Non-vented core

Basket Materials	Pressed steel basket
Cone Composition	Paper cone
Cone Edge Composition	Paper cone edge
Dust Cap Composition	Solid composition felt dust cap
