DV-77-16 12" - Mick Thomson Signature Guitar speaker - 16 ohm

187,00 €

Tasse incluse

non disponibile al momento

Marca

DV-77-16 12" Mick Thomson 12" impedenza 16 ohm, 70w massimi. Cono da 12 pollici, serie Signature, Mick Thomson, magnete in ferrite, cestello custom. Disegnato e approvato da Mick Thomson degli Slipknot

SPECIFICATION
Nominal Basket Diameter	12", 304 mm
Nominal Impedance*	16 Ω
Power Rating*
Program Power	N/A
Watts	70 W
Resonance	73Hz
Usable Frequency Range	70 Hz - 5.3 kHz
Sensitivity*	100.6 dB
Magnet Weight	50 oz.
Gap Height	0.313", 7.95 mm
Voice Coil Diameter	1.75", 44 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)	74 Hz
DC Resistance (Re)	13.27 Ω
Coil Inductance (Le)	0.74m H
Mechanical Q (Qms)	13.48
Electromagnetic Q (Qes)	0.54
Total Q (Qts)	0.52
Compliance Equivalent Volume (Vas)	71.19 liters / 2.51 cu.ft.
Peak Diaphragm Displacement Volume (Vd)	41.04 cc
Mechanical Compliance of Suspension (Cms)	0.19 mm/N
BL Product (BL)	13.18 T-M
Diaphragm Mass Inc. Airload (MMs)	27 grams
Efficiency Bandwidth Product (EBP)	156
Maximum Linear Excursion (Xmax)	0.79 mm
Surface Area of Cone (Sd)	519.5 cm2
Maximum Mechanical Limit (Xlim)	N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed	Acceptable
Vented	Acceptable
Driver Volume Displaced	0.079 cu.ft. / 2.25 liters
Overall Diameter	12.24", 310.9 mm
Baffle Hole Diameter	11.09", 281.69 mm
Front Sealing Gasket	Yes
Rear Sealing Gasket	Yes
Mounting Holes Diameter	0.25", 6.4mm
Mounting Holes B.C.D.	11.69", 296.93mm
Depth	5.19", 131.826 mm
Net Weight	10.4 lbs, 4.72 kg
Shipping Weight	12.1 lbs, 5.49 kgs
MATERIALS OF CONSTRUCTION
Coil Construction	Copper voice coil
Coil Former	Nomex former
Magnet Composition	Ferrite magnet
Core Details	Non-vented core

Basket Materials	Pressed steel basket
Cone Composition	Paper cone
Cone Edge Composition	Paper cone edge
Dust Cap Composition	Zurette dust cap
